SR60 base DIAZED DIII 3-pole 690 V AC 500 V DC for Adapter screw for 5/10 mm busbar thickness with clamp-type terminals
Nomor Part: 5SF6215
Merek
Kategori
D-system fuse base
Siemens 5SF6215. SR60 base DIAZED DIII 3-pole 690 V AC 500 V DC for Adapter screw for 5/10 mm busbar thickness with clamp-type terminals.
Spesifikasi
Mechanical
Net Weight308 g
Dimensions
Width57 mm
Height200 mm
Depth43.5 mm
Other
number of poles3
fastening methodDIN railw
product brand nameSENTRON
supply voltage at AC690 V
design of the productSR60 BASE
design of the fuse basegauge inset
product component coverNo
material of the enclosureothers
