Aktif
DIAZED base DIII 63 A 690 V AC 500 V DC Clamp terminal/saddle terminal
Nomor Part: 5SF1205
Kategori
D-system fuse base
Siemens 5SF1205. DIAZED base DIII 63 A 690 V AC 500 V DC Clamp terminal/saddle terminal.
Spesifikasi
Mechanical
Net Weight175 g
Dimensions
Width46 mm
Height80 mm
Depth47 mm
Other
number of poles1
fastening methodDIN rail
product brand nameSENTRON
supply voltage at AC690 V
design of the productDIAZED base
design of the fuse basegauge inset
product component coverNo
material of the enclosureporcelain
operational current rated value63 A
size of fuse system according to EN 60269-1DIII
