mounting typeclip for 35 mm DIN rail
type of sensorThermal bimetal
fastening methodterminal mounting
mounting positionany
product brand nameSIVACON
product designationtwin thermostat
protection class IPIP20
design of the productNO contact and NO contact
inrush current typical10 A
material of the enclosureplastic
type of connection technology4-pole terminal, solid wire line 2.5 mm2, stranded wire line with end sleeve 1.5 mm2
design of the switching contactSnap-action contact
design of the switching functionNO contact/NO contact
relative humidity reference value90 %
operating voltage at AC rated value250 V
type of voltage of the operating voltageAC
mechanical service life (operating cycles) typical100 000
