mounting typeclip for 35 mm DIN rail
type of sensorThermal bimetal
fastening methodterminal mounting
mounting positionany
product brand nameSIVACON
product designationthermostat
protection class IPIP20
design of the productMechanical
inrush current typical6 A
material of the enclosureplastic
type of connection technology4-pole terminal
design of the switching contactChangeover contact with snap-action contact
operational current rated value10 A
design of the switching functionCO contact
relative humidity reference value90 %
operating voltage at AC rated value230 V
type of voltage of the operating voltageAC
mechanical service life (operating cycles) typical100 000
