Terminal - Siemens | JRB

Terminal

Aktif

Terminal

Nomor Part: 8WH1201-0BJ01

Merek

Kunjungi Situs Web

Kategori

Neutral disconnect terminal block

Permintaan WhatsApp

Siemens 8WH1201-0BJ01. Terminal, screw terminal, installation terminal, N conductor isolating terminal, 10 mm², blue.

Spesifikasi

Mechanical

Net Weight18 g

Dimensions

Height46.9 mm

Depth10.2 mm

Other

colorblue

length55 mm

busbar design3x10 mm

stripped length10 mm

fastening methodTH35 DIN rail

product brand nameSENTRON

insulation materialPA

product designationTerminal blocks

design of the productN-conductor isolating terminal

terminal contact spacing10 mm

number of terminal points2

operating voltage rated value400 V

type of electrical connectionscrew terminal

material of the insulating bodyPA

operational current rated value57 A

height with lowest-profile installation47.5 mm

combustibility class according to UL 94V0

product component required end cover plateYes

Unduhan

8WH1201-0BJ01_doc_0 8WH1201-0BJ01_doc_1 8WH1201-0BJ01_doc_2 8WH1201-0BJ01_doc_3 8WH1201-0BJ01_doc_4 8WH1201-0BJ01_doc_5 8WH1201-0BJ01_datasheet.pdf

Pertanyaan yang Sering Diajukan

Terminal blocks

Neutral disconnect terminal block
