colorgreen-yellow
length70.5 mm
stripped length18 mm
fastening methodTH35 DIN rail
product brand nameSENTRON
insulation materialPA
product designationTerminal blocks
type of connection 1screw-type terminal
type of connection 2screw-type terminal
design of the productPE through-type terminal
position of the terminaltop
terminal contact spacing20 mm
number of terminal levels1
product feature PEN functionNo
material of the insulating bodyPA
height with lowest-profile installation83.5 mm
combustibility class according to UL 94V0
product component required end cover plateNo
number of terminal points per terminal level2
