Aktif
ALPHA 160 DIN flush-mounted board SK2
Nomor Part: 8GK1031-2KK20
Kategori
Empty cabinet
Siemens 8GK1031-2KK20. ALPHA 160 DIN flush-mounted board SK2, h=650 w=550 d=120.
Spesifikasi
Mechanical
Net Weight13.02 kg
Dimensions
Width597 mm
Height697 mm
Depth120 mm
Other
number of rows8
fastening methodflush mounting
RAL color number9 016
installation depth120 mm
product brand nameALPHA
surface processingpowder-coated
IK protection classIK08
product designationWall-mounted cabinet
protection class IPIP31
design of the productflush-mounted empty cabinet
special product featureMasking frame H=708mm B=608mm
material of the enclosureSteel
number of DIN mounting bars0
number of modular width units96
operating resource protection classSafety class 2
suitability for use for outside useNo
product extension optional side-by-side mountingNo
suitability for interaction lightning protectionNo
number of modular width units per DIN mounting bar12
