Aktif
distribution block 1-pole
Nomor Part: 5ST2504
Kategori
Feed-through terminal block
Siemens 5ST2504. distribution block 1-pole, 80 A, IEC 1000 V AC / 1500 V DC; UL 600 V AC/DC; input: 3x 2.5-25 mm2, output: 4x 2.5-6 mm2 for DIN-rail mounting.
Spesifikasi
Mechanical
Net Weight69 g
Dimensions
Height43 mm
Other
colorgrey
length66 mm
fastening methodDIN rail
product brand nameSENTRON
product designationDistribution block
type of connection 1screw-type terminal
type of connection 2screw-type terminal
design of the productdistribution block
position of the terminalbottom
number of terminal levels2
operating voltage rated value1 000 V
material of the insulating bodyOther
operational current rated value80 A
