Aktif
distribution block 4-pole
Nomor Part: 5ST2503
Merek
Kategori
Feed-through terminal block
Siemens 5ST2503. distribution block 4-pole, 160 A, 690 V, input: 1x 10-50 mm2, output: 3x 10-35 mm2 + 8x 2.5-16 mm2 for DIN-rail mounting.
Spesifikasi
Mechanical
Net Weight690 g
Dimensions
Height50 mm
Other
colorgrey
length87 mm
fastening methodDIN rail
product brand nameSENTRON
product designationDistribution block
type of connection 1screw-type terminal
type of connection 2screw-type terminal
design of the productdistribution block
position of the terminalbottom
number of terminal levels4
