design of pole2 poles
number of poles2
product versionfor 5SP4
fastening methodDIN rail
mounting positionany
installation depth70 mm
product brand nameSENTRON
degree of pollution2
product designationRCD-unit
protection class IPIP20, if the distribution board is installed, with connected conductors
— at 40 °C rated value93 A
— at 45 °C rated value93 A
— at 50 °C rated value90 A
— at 55 °C rated value87 A
— at 60 °C rated value85 A
— at 65 °C rated value83 A
— at 70 °C rated value80 A
overvoltage categoryIII
design of the productInstantaneous
residual current typeA
product feature sealableNo
product type designation5SM2
number of modular width units4
position of power supply cordtop or bottom
insulation voltage (Ui) rated value460 V
protection function false trippingYes
tripping fault current rated value30 mA
surge current resistance rated value1 kA
surge voltage resistance rated value4 000 V
reference code according to IEC 81346-2F
value range of the operating frequency50 Hz
product feature OFF-delay time adjustableNo
type of voltage of the operating voltageAC
value range of the supply voltage frequency50 Hz
product feature rated fault current adjustableNo
mechanical service life (operating cycles) typical10 000
size of installation devices according to DIN 438801
touch protection against electrical shock according to EN 50274Finger and back-of-hand safe
number of test cycles for environmental testing according to IEC 60068-2-3028
