Timing relay

Name: Timing relay
Brand: Siemens
SKU: 3RP2505-1AB30-0AC1
Availability: InStock

Nomor Part: 3RP2505-1AB30-0AC1

Merek

Siemens Kunjungi Situs Web

Kategori

Timer relay

Permintaan WhatsApp

Siemens 3RP2505-1AB30-0AC1. Timing relay, multifunction 1 changeover contact, 2 functions (B, K) 7 time ranges (0.05 s...100 h) 24 V AC/DC at 50/60 Hz AC With LED, screw terminal.

Spesifikasi

Mechanical

Net Weight0.132 kg

Other

adjustable time0.05 s ... 100 h

product brand nameSIRIUS

product designationtiming relay

design of the product2 functions (B, K)

product type designation3RP25

Substance Prohibitance (Date)09/12/2014

EMC immunity according to IEC 61812-1corresponds to degree of severity 3

EMC emitted interference according to IEC 61812-1ambience A (industrial sector)

protection class IP on the front according to IEC 60529IP20

product feature protective coating on printed-circuit boardNo

Unduhan

3RP2505-1AB30-0AC1_doc_0 3RP2505-1AB30-0AC1_doc_1 3RP2505-1AB30-0AC1_doc_2 3RP2505-1AB30-0AC1_doc_3 3RP2505-1AB30-0AC1_doc_4 3RP2505-1AB30-0AC1_doc_5 3RP2505-1AB30-0AC1_doc_6 3RP2505-1AB30-0AC1_doc_7 3RP2505-1AB30-0AC1_doc_8 3RP2505-1AB30-0AC1_doc_9 3RP2505-1AB30-0AC1_doc_10 3RP2505-1AB30-0AC1_doc_11 3RP2505-1AB30-0AC1_datasheet.pdf
