Aktif
SITOR fuse holder 50 A 690 V 1-pole with bolt terminal with fixing dimension 75 mm
Nomor Part: 3NH5723
Kategori
Low Voltage HRC fuse base
Siemens 3NH5723. SITOR fuse holder 50 A 690 V 1-pole with bolt terminal with fixing dimension 75 mm.
Spesifikasi
Mechanical
Net Weight183 g
Dimensions
Width28 mm
Height98 mm
Other
number of poles1
fastening methodfixed mounting
product brand nameSENTRON
product designationSITOR fuse holder
utilization categoryWithout
design of the productLV HRC fuse base for screw fixing
fastening method bus-mountingNo
type of electrical connectionfor mounting on mounting plate
product component swivel-in mechanismNo
design of the thread of the connection screwM5
tightening torque with screw-type terminals maximum2 N·m
