Smart Temp - Preheater
Brand
Category
Gauges and Instruments
Smart Temp range of wire preheaters makes your extrusion process faster and easier, improving product quality and productivity. They provide uniform, in-process wire heating to eliminate insulation voids in primary cables.
Specifications
Other
Wire Size0.28-1.4 mm (0.01 - 0.055 in.)
29-15 AWG Stranded wire up to 2.5 mm2 / 0.45-2.8 mm (0.02 - 0.11 in.)
25-9 AWG Stranded wire up to 6 mm2 / 0.37-1.4 mm (0.015 - 0.055 in.)
27-15 AWG
Pulley Size2 x 120 mm (2 x 4.7 in.) / 2 x 280 mm (2 x 11 in.) / 2 x 190 & 2 x 120 mm
Power Output8 KVA/400v version
6 KVA/200v version / 16 KVA / 16 KVA
Max. Loop Volt17 V / 40 V / 40 V
Max. Line Speed1500 m/min. (4900 ft./min.) / 2500 m/min. (8200 ft./min.) / 2500 m/min. (8200 ft./min.)
Max. Wire Temperature190°C (370°F) / 190°C (370°F) / 400°C (750°F)
