Active
SCALANCE MUB852-1 (A1) 5G router
Part Number: 6GK5852-1EA10-1AA1
Brand
Category
Network router
Siemens 6GK5852-1EA10-1AA1. SCALANCE MUB852-1 (A1) 5G router, IP20, for wireless IP communication from Ethernet-based applications via public 3G/4G/5G mobile radio networks and private 5G networks, VPN (in combination with SINEMA RC device license) firewall, NAT, IPv6, connection to SINEMA RC, 4 SMA connections, 1x nano SIM slot, 1x10/100/1000 Mbps RJ45 port, 24 V DC 0 to +55 °C, region version A1 observe national approvals! siemens.com/mobile-approvals CERT ID: EL5G16R-20-M1-RJ-E4-1.
Specifications
Mechanical
Net Weight200 g
Dimensions
Width50 mm
Height114 mm
Depth74 mm
Other
fastening methodmounting on DIN rail
firewall versionStatefull Inspection
protection class IPIP20
security informationSiemens provides products and solutions with industrial cybersecurity functions that support the secure operation of plants, systems, machines and networks. In order to protect plants, systems, machines and networks against cyber threats, it is necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial cybersecurity concept. Siemens’ products and solutions constitute one element of such a concept. Customers are responsible for preventing unauthorized access to their plants, systems, machines and networks. Such systems, machines and components should only be connected to an enterprise network or the internet if and to the extent such a connection is necessary and only when appropriate security measures (e.g. firewalls and/or network segmentation) are in place. For additional information on industrial cybersecurity measures that may be implemented, please visit www.siemens.com/cybersecurity-industry. Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customer’s exposure to cyber threats. To stay informed about product updates, subscribe to the Siemens Industrial Cybersecurity RSS Feed under https://www.siemens.com/cert. (V4.7)
type of configurationWeb-based management
supply voltage / 1 / rated value24 V
number of slots / for Micro-SIM card1
product component / eSIM integratedNo
design of the removable storage / CLPNo
transfer rate / for Industrial Ethernet10, 100, 1000 Mbit/s
type of wireless network / is supported5G public networks, 5G private networks, LTE, UMTS
type of mobile wireless service / is supportedHSDPA, HSUPA, HSPA+
product function / is supported / identification linkYes; acc. to IEC 61406-1:2022
suitability for operation / Virtual Private NetworkYes
relative humidity / at 25 °C / during operation / maximum95 %
type of authentication / with Virtual Private Network / PSKNo
IETF profile / with Virtual Private Network / X.509v3 certificateNo
number of electrical/optical connections / for gigabit Ethernet / maximum1
number of electrical/optical connections / for network components or terminal equipment / maximum1
