colorblack
length61.5 mm
fastening methodTH35 DIN rail
product brand nameSENTRON
insulation materialPA
product designationTerminal blocks
type of connection 1spring-loaded terminals
type of connection 2spring-loaded terminal
design of fuse holderswivel
design of the productfuse terminal
design of the fuse linkglass fuse 5x20 mm
position of the terminaltop
terminal contact spacing6.2 mm
number of terminal levels1
operating voltage rated value250 V
material of the insulating bodyOther
operational current rated value6.3 A
height with lowest-profile installation61.53 mm
combustibility class according to UL 94V0
type of light source as defect indicatorwithout
product component required end cover plateNo
type of voltage for supply of the defect indicatorothers
