colorgrey
length67 mm
fastening methodTH35 DIN rail
product brand nameSENTRON
insulation materialPA
product designationTerminal blocks
type of connection 1screw-type terminal
type of connection 2screw-type terminal
design of the productthrough-type terminal
position of the terminallateral
terminal contact spacing6 mm
number of terminal levels1
operating voltage rated value800 V
material of the insulating bodyPA
operational current rated value41 A
height with lowest-profile installation66.5 mm
combustibility class according to UL 94V0
number of terminal points per terminal level2
design of terminal terminal levels internally linkedNo
