mounting typeclip for 35 mm DIN rail
type of sensorThermal bimetal
fastening methodterminal mounting
mounting positionany
product brand nameSIVACON
protection class IPIP20
design of the productNC contact
inrush current typical16 A
material of the enclosureplastic
type of connection technology2-pole terminal 2.5 mm2
design of the switching contactSnap-action contact
operational current rated value3 A
design of the switching functionNC contact
relative humidity reference value90 %
operating voltage at AC rated value250 V
type of voltage of the operating voltageAC
mechanical service life (operating cycles) typical100 000
