colorwhite
number of rows3
fastening methodSurface mounting
RAL color number9 010
installation depth70 mm
product brand nameALPHA
product designationSIMBOX XL
protection class IPIP30
design of support railStandard mounting rail 35 mm x 7.5 mm acc. to EN 60715
rotation angle of door135°
material of the enclosureplastic
design of the cap/top coverclosed
equipment of terminal strip1x8GB5015-5KM, 1x8GB5011-5KM
design of the terminal stripScrew terminal
busbar center-to-center spacing125 mm
number of modular width units12
design of the product EMC versionNo
operating resource protection classII
operating voltage at AC rated value400 V
product extension optional side-by-side mountingNo
