fastening methodWall mounting, mounting on a DIN rail with a separate mounting adapter
firewall versionStatefull Inspection
protection class IPIP65
security informationSiemens provides products and solutions with industrial cybersecurity functions that support the secure operation of plants, systems, machines and networks. In order to protect plants, systems, machines and networks against cyber threats, it is necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial cybersecurity concept. Siemens’ products and solutions constitute one element of such a concept. Customers are responsible for preventing unauthorized access to their plants, systems, machines and networks. Such systems, machines and components should only be connected to an enterprise network or the internet if and to the extent such a connection is necessary and only when appropriate security measures (e.g. firewalls and/or network segmentation) are in place. For additional information on industrial cybersecurity measures that may be implemented, please visit www.siemens.com/cybersecurity-industry. Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customer’s exposure to cyber threats. To stay informed about product updates, subscribe to the Siemens Industrial Cybersecurity RSS Feed under https://www.siemens.com/cert. (V4.7)
type of configurationWeb-based management
number of digital inputs1
number of digital outputs1
supply voltage / 1 / rated value24 V
supply voltage / 2 / rated value24 V
supply voltage / 3 / rated value48 V
Environmental Product DeclarationYes
number of slots / for Micro-SIM card1
product component / eSIM integratedYes
design of the removable storage / CLPYes
input voltage / at digital input / at DC-30 ... +30 V
transfer rate / for Industrial Ethernet10, 100, 1000 Mbit/s
type of wireless network / is supported5G public networks, 5G private networks, LTE, UMTS
type of mobile wireless service / is supportedHSDPA, HSUPA, HSPA+
output voltage / at digital output / at DC / maximum24 V; 0,5 A
product function / is supported / identification linkYes; acc. to IEC 61406-1:2022
suitability for operation / Virtual Private NetworkYes
number of possible connections / with VPN connection20
relative humidity / at 25 °C / during operation / maximum95 %
type of authentication / with Virtual Private Network / PSKYes
type of electrical connection / at the digital inputs/outputsM12 (4-pin, A-coded)
type of packet authentication / with Virtual Private NetworkMD5, SHA-1, SHA-256, SHA-384, SHA-512
IETF profile / with Virtual Private Network / X.509v3 certificateYes
operational current / of the signaling contacts / at DC / at 30 V / maximum0.008 A
number of electrical/optical connections / for gigabit Ethernet / maximum1
supply voltage / from Power-over-Ethernet according to IEEE802.3at for type 1 and IEEE802.3af48 V
number of electrical/optical connections / for network components or terminal equipment / maximum1
