range20 ... 375 mm
range / noteCode-dependent
accessoriesRS232 cable with power supply, USB cable, stand
type of battery--
type of focusingFixed focus, optimum focal point at 6.3 mm
type of programmingOptical parameterization or via configuration software
security informationSiemens provides products and solutions with industrial cybersecurity functions that support the secure operation of plants, systems, machines and networks. In order to protect plants, systems, machines and networks against cyber threats, it is necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial cybersecurity concept. Siemens’ products and solutions constitute one element of such a concept. Customers are responsible for preventing unauthorized access to their plants, systems, machines and networks. Such systems, machines and components should only be connected to an enterprise network or the internet if and to the extent such a connection is necessary and only when appropriate security measures (e.g. firewalls and/or network segmentation) are in place. For additional information on industrial cybersecurity measures that may be implemented, please visit www.siemens.com/cybersecurity-industry. Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customer’s exposure to cyber threats. To stay informed about product updates, subscribe to the Siemens Industrial Cybersecurity RSS Feed under https://www.siemens.com/cert. (V4.7)
type of light sourceLighting system comprising incident light (red)
design of the display2 LEDs
height of fall / maximum1.8 m
type of current supplyVia USB or external plug-type power supply unit (RS232), 5 V, 410 mA
design of the interfaceUSB, RS232
fastening method / of lensIntegrated
operator element versionTrigger in handle
suitability for operation1D/2D: Aztec, Codabar, Codablock F, Code 11, Code 39, Code 39 Short Margin, Code 39 Extended Full ASCII, Code 39 Checksum, Code 93, Code 128, Code 128 Short Margin, Composite, Data Matrix, Data Matrix Rectangle, Data Matrix Inverse, GS1 DataBar (all), Interleaved 2of5, Interleaved 2of5 - 2 Digits, Macro PDF417, Maxicode, Matrix 2of5, Micro PDF417, MSI Plessy, NEC 2of5, OCR, PDF417, Postal Codes (All), QR Code, Telepen, UPC, UPC Short Margin, UPC Extension
product function / of the softwareRead, display, save, transfer codes
picture recording frequency / maximum10 Hz
design of acoustic signaling elementVibration alarm, audible signal
design of image sensor / of the cameraCMOS 1280 x 960, image resolution 960 x 640
relative humidity / at 25 °C / without condensation / during operation / maximum95 %
