Cable length0.19 m
Cable designation4 Li9Y 0.50 mm² Y
Weight per length44 kg/km
Product descriptionFlexible cable (4-core), preassembled at each end with a 4-pin M8 male / female connector
Suitability for useFor connection to ET 200AL for 24 V DC power supply
Outgoing feeder type180° cable outlet
Color of cable sheathgray
IP degree of protectionIP65/67
Material of cable sheathPVC
Number of bending cycles2 500 000; cable carrier compliant for 2.5 million bending cycles with a bending radius of 52 mm, a speed of 3 m/s and an acceleration of 10 m/s²
Product type designationPower cable
Number of electrical cores4
Material of core insulationPP
Outer diameter of cable sheath5.2 mm
Outer diameter of core insulation1.46 mm
Outer diameter of inner conductor0.8 mm
Bending radius for continuous bending52 mm
Ambient temperature during assembly, max.80 °C
Ambient temperature during assembly, min.-30 °C
Color of core insulation of energy corewhite / brown / blue / black
Permissible bending radius, single bend, min.26 mm
Permissible bending radius, multiple bends, min.52 mm
