relay designpartially electronic
fastening methodDIN rail
mounting positionany
installation depth70 mm
product brand nameSENTRON
product designationSwitching relays
protection class IPIP20, with connected conductors
design of the productWith 4 NO
number of CO contacts0
number of NC contacts0
number of NO contacts4
number of modular width units2
operating frequency rated value50 Hz
required spacing for live parts6 mm
design of the switching function4 NO
width of opening of the contacts1.2 mm
product function direct operationYes
surge voltage resistance rated value4 kV
electrical endurance (operating cycles)50 000
type of voltage of the supply voltageAC
number of terminals with cross-head screw1
switching capacity current at cos phi 0.616 A
type of voltage of the operating voltageAC
control voltage at AC rated value maximum115 V
operating range factor of control voltage_10.8
operating range factor of control voltage_21.1
switching current at AC per contact minimum100 mA
switching voltage of the contacts at AC minimum10 V
galvanic isolation between magnet coil and contactYes
power loss [V∙A] of magnet coil with pulse rated value6 VA
switching capacity active power with incandescent lamp load1 200 W
