colorlight grey
length212 mm
cross-section10 mm²
module width18 mm
phase number1
compatibilityfor 12 MCBs 1P
design of pole1 pole
product brand nameSENTRON
product designationPin busbar
design of the product12x 1PH
design of the phase tapL1/L1
product feature insulatedYes
angle of the pin of busbar0°
number of modular width units12
type of electrical connectionPin
operational current rated value63 A
number of devices suitable for fitting12
suitability for interaction devices with N conductorNo
product feature attachable arc fault detection deviceNo
suitability for interaction devices with auxiliary switchNo
