type of voltageAC/DC
fastening methodscrew and snap-on mounting
product categorySafety relays
shock resistance10g / 11 ms
mounting positionany
product brand nameSIRIUS
degree of pollution3
product designationPower supply
overvoltage category3
power loss [W] maximum2.5 W
consumed current maximum0.25 A
EMC emitted interferenceIEC 60947-5-1, Class A
product type designation3SK1
Substance Prohibitance (Date)11/05/2012
type of electrical connectionspring-loaded terminal (push-in)
insulation voltage rated value300 V
design of short-circuit protectionautomatically start-up
air pressure according to SN 31205900 ... 1 060 hPa
relative humidity during operation10 ... 95 %
protection class IP of the enclosureIP20
surge voltage resistance rated value4 000 V
certificate of suitability UL approvalYes
reference code according to IEC 81346-2T
control supply voltage at DC rated value110 ... 240 V
property of the output short-circuit proofYes
suitability for use safety-related functionYes
vibration resistance according to IEC 60068-2-65 ... 500 Hz: 0.75 mm
installation altitude at height above sea level maximum4 000 m
