repeat accuracy0.05 mm
thermal current10 A
active principlemechanical
cable entry type1x (M20 x 1.5)
fastening methodscrew fixing
circuit principleslow-action contacts
mounting positionany
product brand nameSIRIUS
degree of pollutionclass 3
product designationMechanical safety switches
protection class IPIP66/IP67
width of the sensor40 mm
length of the sensor85.7 mm
service life maximum20 a
design of the housingblock, narrow
design of the interfacewithout
coating of the enclosurecathodic dip coating
product type designation3SE5
material of the enclosuremetal
Substance Prohibitance (Date)07/01/2006
type of electrical connectionscrew terminal
insulation voltage rated value400 V
design of the actuating elementOther, without, basic switch
design of the switching contactmechanical
operating frequency rated value50 ... 60 Hz
design of the switching functionPositive opening with appropriate positive opening actuator head
product function positive openingYes
suitability for use safety switchYes
device type according to ISO 13849-13
surge voltage resistance rated value6 kV
explosion protection category for dustnone
reference code according to IEC 81346-2B
test wear-related service life necessaryYes
number of switching contacts safety-related1
design of the housing according to standardYes
number of NC contacts for auxiliary contacts1
number of NO contacts for auxiliary contacts1
continuous current of the DIAZED fuse link gG6 A
product function suitable for safety functionYes
vibration resistance according to IEC 60068-2-60.35 mm/5g
continuous current of the C characteristic MCB1 A; for a short-circuit current smaller than 400 A
continuous current of the quick DIAZED fuse link10 A; for a short-circuit current smaller than 400 A
mechanical service life (operating cycles) typical15 000 000
minimum actuating force in directions of actuation20 N
B10 value with high demand rate according to SN 3192010 000 000
design of the interface for safety-related communicationwithout
failure rate [FIT] with low demand rate according to SN 31920100 FIT
electrical endurance (operating cycles) at AC-15 at 230 V typical100 000
