— upwards0 mm
— forwards0 mm
rise time6 ms
— backwards0 mm
— downwards0 mm
— at the side0 mm
limit frequency30 Hz
type of voltageAC/DC
fastening methodsnap-on mounting
product categorySignal converter
mounting positionany
number of channels1
product brand nameSIRIUS
display version LEDYes
product designationSingle-range converters
consumed active power0.29 W
design of the productactive
input voltage maximum30 V
voltage ripple maximum20 mV
temperature drift per °C0.015 %/°C
type of signal at input0 ... 20 mA
product type designation3RS70
type of signal at output0 ... 10 V
relative metering precision0.1 %
Substance Prohibitance (Date)03/25/2015
relative linearity deviation0.05 %
settling time for 1 % deviation17 ms
type of electrical connectionspring-loaded terminal (push-in)
supply voltage at DC rated value24 V
design of the electrical isolation3 paths
relative humidity during operation10 ... 95 %
EMC immunity according to IEC 60947-1corresponds to degree of severity 3
supply voltage frequency rated value60 ... 50 Hz
surge voltage resistance rated value2 500 V
reference code according to IEC 81346-2T
input impedance of current input maximum100 Ω
property of the output short-circuit proofYes
shock resistance according to IEC 60068-2-27sinusoidal half-wave 15g / 11 ms
vibration resistance according to IEC 60068-2-66 ... 150 Hz: 2 g
electrostatic discharge according to IEC 61000-4-26 kV contact discharge / 8 kV air discharge
EMC emitted interference according to IEC 60947-1Environment B
field-based interference according to IEC 61000-4-310 V/m
installation altitude at height above sea level maximum2 000 m
insulation voltage for overvoltage category III according to IEC 60664 with degree of pollution 3 rated value50 V
