type of voltageDC
fastening methodDIN rail
product categoryModular Safety System
shock resistance15g / 11 ms
mounting positionvertical
product brand nameSIRIUS
degree of pollution3
design of the product4 F-DO
Substance Prohibitance (Date)05/01/2012
category according to EN 954-14
type of electrical connectionscrew terminal
insulation voltage rated value50 V
relative humidity during operation10 ... 95 %
category according to EN ISO 13849-14
surge voltage resistance rated value500 V
reference code according to IEC 81346-2K
touch protection against electrical shockfinger-safe
control supply voltage 1 at DC rated value24 V
performance level (PL) according to ISO 13849-1PL e
vibration resistance according to IEC 60068-2-65 ... 500 Hz: 0.75 mm
performance level (PL) according to EN ISO 13849-1e
electrostatic discharge according to IEC 61000-4-24 kV contact discharge / 8 kV air discharge
field-based interference according to IEC 61000-4-310 V/m, 3 V/m, 1 V/m
PFHD with high demand rate according to IEC 620610 1/h
Safety Integrity Level (SIL) according to IEC 615083
Safety Integrity Level (SIL) according to IEC 62061SIL 3
number of outputs for testing contact-based sensors0
installation altitude at height above sea level maximum2 000 m
switching capacity current of semiconductor outputs at DC-13 at 24 V2 A
T1 value for proof test interval or service life according to IEC 6150820 a
Average probability of failure on demand (PFDavg) with low demand rate acc. to IEC 615082.2E-5 1/y
