AS-i compact module K45 digital 4 DI

Name: AS-i compact module K45 digital 4 DI
Brand: Siemens
SKU: 3RK1200-0CQ20-0AA3
Availability: InStock

Nomor Part: 3RK1200-0CQ20-0AA3

Merek

Kunjungi Situs Web

Kategori

Fieldbus, decentr. periphery - digital I/O module

Siemens 3RK1200-0CQ20-0AA3. AS-i compact module K45 digital 4 DI, IP67 4 x input, maximum 200 mA 4 x M12 socket Mounting plate 3RK1901-2EA00 or 3RK1901-2DA00 must be ordered separately.

Spesifikasi

Dimensions

Width45 mm

Height80 mm

Depth30 mm

Other

input voltage20 ... 30 V

fastening methodstandard rail mounting/wall mounting using mounting plate for K45 compact module

shock resistance15g / 11 ms

protection class IPIP67

design of the productdigital I/O modules for operation in the field, IP67 - K45

number of digital inputs4

design of the device typestandard slave

number of digital outputs0

type of connection technology2- and 3-wire technology

type of voltage of the input voltagesDC

type of voltage supply for sensor supplyusing AS-Interface

design of the pin assignment of the inputsstandard assignement

type of electrical connection of the inputs and outputsM12 screw-type terminals

property of the sensor supply short-circuit and overload resistantYes
