fuse systemLV HRC fuse
type of deviceFor busbar system 100 mm
number of poles3
fastening methodFlachanschluss, M 8
mounting positionvertical, horizontal
size of fuse linkNH000, NH00
product brand nameSENTRON
product designationFuse switch disconnectors
number of poles note3-pole switchable
design of the productin in-line design
suitability for operationSystem protection
busbar center-to-center spacing100 mm
insulation voltage rated value800 V
design of the auxiliary releaseWithout
design of the safety monitoringElectronic
suitability for use main switchNo
protection class IP on the frontIP30
suitability for use safety switchNo
design of the load switch strip formYes
suitability for use switch disconnectorYes
suitability for use EMERGENCY OFF switchNo
suitability for use maintenance/repair switchNo
type of electrical connection for main current circuitM8 busbar connection
type of switching contact double breaking switching contactNo
arrangement of electrical connectors for main current circuitFlat terminal
