Aktif
ZK507 - Single- and multi-pole terminal strip
Nomor Part: 2CPX030892R9999
Kategori
Single- and multi-pole terminal strip
ABB ZK507. Single- and multi-pole terminal strip. featuring rated current in 63EU570459, number of poles 1, dimensions 25mm x 36EU570448.
Spesifikasi
Mechanical
Net Weight0.021 kg
Dimensions
Width25 mm
Height36 EU570448
Depth15 mm
Other
ColourBlue
Length40 mm
TransparentNo
Halogen freeNo
Mounting methodDirect mounting
Number of poles1
Rated current In63 EU570459
Operating temperature55
Closing plate requiredNo
Material insulation bodyThermoplastic
Explosion-tested version 'Ex e'No
Type of electrical connection 1Screw connection
Type of electrical connection 2Screw connection
Number of clamp positions per pole55
Connectable conductor cross section fine-strand with cable end sleeve0
Connectable conductor cross section fine-strand without cable end sleeve0
