accessories24 V DC screw terminal included in scope of delivery
wireless approvalYou will find the current list of countries at: www.siemens.de/funkzulassungen
protection class IPIP20
security informationSiemens provides products and solutions with industrial cybersecurity functions that support the secure operation of plants, systems, machines and networks. In order to protect plants, systems, machines and networks against cyber threats, it is necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial cybersecurity concept. Siemens’ products and solutions constitute one element of such a concept. Customers are responsible for preventing unauthorized access to their plants, systems, machines and networks. Such systems, machines and components should only be connected to an enterprise network or the internet if and to the extent such a connection is necessary and only when appropriate security measures (e.g. firewalls and/or network segmentation) are in place. For additional information on industrial cybersecurity measures that may be implemented, please visit www.siemens.com/cybersecurity-industry. Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customer’s exposure to cyber threats. To stay informed about product updates, subscribe to the Siemens Industrial Cybersecurity RSS Feed under https://www.siemens.com/cert. (V4.7)
product function / iPRPNo
product function / iREFNo
standard / for hazardous zoneEN 60079-15:2005, EN 60079-0:2006, II 3 G Ex nA II T4 KEMA 07 ATEX 0145X
product function / client ModeYes
ambient condition / for operationWhen used under hazardous conditions (Zone 2), the SCALANCE W761-1 RJ45 or W72x-1 RJ45 product must be installed in an enclosure. To comply with EN 50021, this enclosure must meet the requirements of at least IP 54 in compliance with EN 60529.
Environmental Product DeclarationYes
product function / Access Point ModeNo
type of voltage / of the supply voltageDC
depth / of the enclosure / without antenna74 mm
width / of the enclosure / without antenna50 mm
height / of the enclosure / without antenna114 mm
number of manageable IP addresses / in client4
number of radio cards / permanently installed1
product function / is supported / identification linkYes; acc. to IEC 61406-1:2022
type of electrical connection / for external antenna(s)R-SMA (socket)
number of electrical connections / for external antenna(s)1
product feature / external antenna can be mounted directly on deviceYes
relative humidity / at 25 °C / without condensation / during operation / maximum95 %
certificate of suitability / CCC / for hazardous zone according to GB standardYes; GB3836.1, GB3836.8
