DesignRack PC, 19", 4U
ChipsetIntel®Q670
IP (rear)IP20
MountingFor horizontal and vertical mounting
USB port8x USB3.2 on rear panel, 2x USB2.0 on front panel, 2x USB2.0 vertical and 1x USB2.0 pin header on motherboard
— 100 MbpsYes
Hard diskHDD & SSD
— 1000 MbpsYes
Processor typeIntel® Celeron G6900 with 2 cores / 2 threads; Intel® Pentium G7400 with 2 cores / 4 threads; Intel® Core™ i3 with 4 cores / 8 threads, Core™ i5 with 6 cores/12 threads, Core™ i7 with 12 cores / 20 threads, Core™ i9 with 16 cores / 24 threads.
Type of memory4x non-ECC UDIMM slots for DDR4
IP (at the front)IP20
serial interface1x RS232 and 1x RS232/422/485 at rear panel, 3x RS232 and 1x RS232/485 on mainboard
LED status displayPOWER, HDD
Type of supply voltage100 - 240 V AC
Product type designationRW-543B
without operating systemYes
Capacity of main memory, max.32 Gbyte
pre-installed operating systemWindows 10 Enterprise 2021 LTSC, 64-bit, MUI
— global warming potential, (total) [CO2 eq]1 060 kg
— global warming potential, (during operation) [CO2 eq]964 kg
— global warming potential, (during production) [CO2 eq]112 kg
— global warming potential, (after end of life cycle) [CO2 eq]-22.9 kg
