colorlight grey
length250 mm
cross-section10 mm²
module width18 mm
phase number3
compatibilityfor 14 MCBs 3P
design of pole3 poles
product brand nameSENTRON
product designationPin busbar
design of the product14x 3PH
design of the phase tapL1/L2/L3
product feature insulatedYes
angle of the pin of busbar0°
number of modular width units14
type of electrical connectionPin
operational current rated value63 A
number of devices suitable for fitting14
suitability for interaction devices with N conductorNo
product feature attachable arc fault detection deviceNo
suitability for interaction devices with auxiliary switchNo
