product extensionauxiliary switch
product brand nameSENTRON
product designationauxiliary switches
protection class IPIP20
design of the productMountable
number of CO contacts0
number of NC contacts1
number of NO contacts1
number of modular width units1
insulation voltage rated value50 V
number of fault signal contacts0
product extension can be mountedUniversal
type of voltage of control voltageAC/DC
surge voltage resistance rated value1 kV
design of the product factory mountedNo
operational current at DC rated value0.005 ... 0.05 A
ambient temperature during storage minimum-40 °C
electrical endurance (operating cycles) typical10 000
