twist lever for position switch 3SE51 metal lever 27 mm long

Name: twist lever for position switch 3SE51 metal lever 27 mm long
Brand: Siemens
SKU: 3SE5000-0AA07
Availability: InStock

Part Number: 3SE5000-0AA07

Brand

Visit Website

Specifications

Mechanical

Net Weight0.033 kg

Other

active principlemechanical

fastening methodscrew fixing

mounting positionany

product brand nameSIRIUS

product designationactuator for part-turn actuator

design of the interfacewithout

coating of the enclosureOther types

product type designation3SE5

shape of the switch headroller

Substance Prohibitance (Date)07/01/2006

design of the actuating elementTwist lever, metal lever, 27 mm long, step 9 mm, plastic roller 50 mm

standard-compliant actuator headEN 50041, design A

outer diameter of the switch head50 mm

product function positive openingYes

explosion protection category for dustnone

reference code according to IEC 81346-2T

mechanical service life (operating cycles) typical15 000 000

design of the interface for safety-related communicationwithout
