OFF-delay device
Part Number: 3RT2916-2BL01
Brand
Category
Amplifier module for contactor
Siemens 3RT2916-2BL01. OFF-delay device, 220/230 V AC/DC, 50/60 Hz, for contactors 3RT2 and auxiliary contactors 3RH2 with AC/DC and DC operation.
Specifications
Mechanical
Net Weight0.154 kg
Other
fastening methodscrew and snap-on mounting onto 35 mm DIN rail
product categoryOFF-delay device
mounting positionany
size of contactorS00, S0
product brand nameSIRIUS
product designationOFF-delay device
design of the productOFF delay device
product type designation3RT29
Substance Prohibitance (Date)10/01/2009
control supply voltage 1 at DC200 ... 240 V
product component protective wiringNo
touch protection against electrical shockfinger-safe
type of voltage of the control supply voltageAC/DC
type of electrical connection for auxiliary and control circuitscrew-type terminals
