SIMATIC ET 200SP communications module CM AS-i Master ST according to AS-Interface specification V3.0
Part Number: 3RK7137-6SA00-0BC1
Brand
Category
PLC communication module
Siemens 3RK7137-6SA00-0BC1. SIMATIC ET 200SP communications module CM AS-i Master ST according to AS-Interface specification V3.0.
Specifications
Dimensions
Width20 mm
Height69.2 mm
Depth53.6 mm
Other
power loss [W]1.7
module formatIP20
— at 30 V maximum70
fastening methodpluggable in BaseUnit
product designationCM AS-i Master ST
protection class IPIP20
type of voltage supplyVia AS-i and backplane bus
access to analog I/O datavia process diagram/peripheral addresses and data record transfer
product type designationET 200SP
access to digital I/O datavia process image/peripheral addresses
type of data transmissionET 200SP backplane bus
insulation voltage rated value500
— at 24 V with AS-i Power24V maximum70
product component optical interfaceNo
explosion protection category for gasII 3 G Ex ec IIC T4 Gc
product feature redundancy capabilityYes
explosion protection category for dustnone
AS-Interface master profile is supportedM4 (in acc. with AS-interface specification V 3.0)
number of inputs for AS-Interface maximum496
type of configuration of the AS-InterfaceSET pushbutton (optional) on the device, STEP 7, GSD, command interface
version of the AS-Interface specificationV 3.0
number of outputs for AS-Interface maximum496
product function suitable for AS-i Power24VYes
suitability for use safety-related functionNo
number of AS-i devices per AS-Interface maximum62
standard for wireless communication IEEE 802.11No
type of electrical connection of the AS-InterfaceET 200SP BaseUnit (Type C0), 20 mm
relative humidity at 25 °C during operation maximum95
installation altitude at height above sea level maximum2 000
product function suitable for operation on PROFINET R1 IMsYes
