profile7.3
output quantityV
fastening methodstandard rail mounting/wall mounting using mounting plate for K60 compact module
protection class IPIP67
design of the productanalog I/O modules for operation in the field, IP67 - K60
number of analog inputs0
number of analog outputs2
design of the device typeanalog slave
A/D resolution for analog inputs/outputs12
product function parameterizable output variableYes
type of electrical connection of the inputs and outputsM12 screw-type terminals
consumed current from profile conductors of the AS-Interface at 30 V maximum160
